Khoom piav qhia:
SC (B) 10/11 Epoxy CastQhuav hom Transformeryog structurally distinguished los ntawm subsection cylindrical windings cam khwb cia rau hauv tsim los ntawm tws iav fiber nrog axial cua passageways muab rau sab hauv kom tso cai rau tshav kub diffusion. Qhov tsim nyog cam khwb cia technology pab resin nkag mus rau txhua qhov sib txawv ntawm windings, txheej thiab subsections kom ntseeg tau tias cov hluav taws xob rwb thaiv tsev lub zog thiab ib feem qis tus nqi (tsawg dua los yog sib npaug rau 5pc).
Kev tiv thaiv ntawm kev tawg ntawm castings, txwv tsis pub npuas hauv qhov casting thiab txo cov nqi tso tawm ib nrab mus rau qhov tsawg kawg nkaus yog ib txwm suav tias yog ib qho kev sib tw zoo rau cov tuam txhab hloov pauv thoob ntiaj teb thiab tseem ceeb heev rau kev tsim cov cam khwb cia qhuav-hom transformer.
Khoom nta:
1. Daim tawv nqaij tawm ntawm txheej encapsulating resin tso cai kom zoo dua tshav kub diffusion ntawm coils;
2. Cov coils tau sib sau ua ke los ntawm iav fiber ntau daim ntaub kom nws cov khoom siv dag zog thiab muaj peev xwm tiv thaiv qhov tshwm sim luv luv thiab yog li tiv thaiv
tawg ntawm castings;
3. Kev txais yuav kev ua haujlwm tshwj xeeb ntawm cov coils pab txo qis sab hauv ib feem ntawm cov coils ua kom muaj zog thiab ua kom muaj zog hluav taws xob;
4. Cov qauv ntawv nyiaj rau LV windings pab txo cov coil-kawg sib nqus nqus thiab ua rau kom muaj kev tiv thaiv rau qhov tshwm sim luv luv.
|
Cov ntaub ntawv ntawm 35kV SC (B) 10 Cast Resin F Rwb thaiv tsev Chav Kawm Qhuav Hom Fais Fab Transformer
|
||||||||||||||
|
|
Lossis (kW) | Rwb thaiv tsev Level | Qhov hnyav (kg) | Daim ntawv Dimension (mm) | Tshaj tawm qhov ntev nrog kev tiv thaiv casing | |||||||||
| Rated Peev Xwm | Voltage pawg (kV) | Txoj kev sib txuas | (120) | Tsis muaj load tam sim no | (L) | (W) | (H) | (L) | (W) | (H) | ||||
| (kVA) | HV | LV | Tsis muaj load | Thauj khoom | % | |||||||||
| 50 | 0.5 | 1.5 | 2.8 | 610 | 1000 | 870 | 1160 | 1700 | 1400 | 1330 | ||||
| 100 | 0.7 | 2.2 | 2.4 | 915 | 1100 | 870 | 1350 | 1800 | 1400 | 1500 | ||||
| 160 | 0.88 | 2.96 | 1.8 | 1200 | 1500 | 870 | 1380 | 2200 | 1500 | 1600 | ||||
| 200 | 0.98 | 3.5 | 1.8 | 1400 | 1530 | 870 | 1420 | 2250 | 1500 | 1650 | ||||
| 250 | 1.1 | 4 | 1.6 | 1600 | 1550 | 870 | 1450 | 2300 | 1500 | 1700 | ||||
| 315 | 1.31 | 4.75 | 1.6 | F/F | 1800 | 1580 | 870 | 1550 | 2300 | 1600 | 1800 | |||
| 400 | Dyn 11 | 1.53 | 5.7 | 1.4 | 2200 | 1740 | 870 | 1710 | 2450 | 1600 | 1950 | |||
| 500 | 35~38.5 | 0.4 | 1.8 | 7 | 1.4 | 2500 | 1740 | 870 | 1900 | 2450 | 1600 | 2100 | ||
| 630 | Yyn 0 | 2.07 | 8.1 | 1.2 | 2900 | 1860 | 870 | 1980 | 2550 | 1700 | 2250 | |||
| 800 | 2.4 | 9.6 | 1.2 | 3500 | 1860 | 870 | 2180 | 2550 | 1700 | 2400 | ||||
| 1000 | 2.7 | 11 | 1 | 4200 | 1900 | 1120 | 2265 | 2600 | 1800 | 2500 | ||||
| 1250 | 3.15 | 13.4 | 0.9 | 4900 | 1950 | 1120 | 2355 | 2650 | 1800 | 2600 | ||||
| 1600 | 3.6 | 16.3 | 0.9 | 5800 | 2000 | 1120 | 2380 | 2700 | 1800 | 2650 | ||||
| 2000 | 4.25 | 19.2 | 0.9 | 6600 | 2100 | 1120 | 2480 | 2800 | 1800 | 2700 | ||||
| 2500 | 4.95 | 23 | 0.9 | 7500 | 2200 | 1120 | 2550 | 2900 | 1800 | 2800 | ||||
GNEE SC (B) 10/11 Epoxy Cast Dry-Type Transformer
HAIS TIAS
FQA
Q: Tus nqi shipping yog dab tsi?
A: Nyob ntawm qhov chaw nres nkoj ntawm kev xa khoom, tus nqi sib txawv.
Q: Dab tsi yuav tsum muab los ua kev cai transformer?
A: Kev kos duab kos duab thiab cov ntaub ntawv qhia tshwj xeeb yog qhov zoo tshaj plaws, lossis koj tuaj yeem sau cov ntsiab lus tseem ceeb rau kev tsim.
Q: Kuv puas tuaj yeem muaj koj daim ntawv teev npe thiab nqe?
A: Tus nqi yuav hloov raws li cov khoom lag luam. Txais tos hu rau tus nqi raug ntawm Made-in-China lossis tuam txhab official lub vev xaib.
Q: Koj puas muab cov qauv dawb ntawm galvanized steel hlau los xij?
A: Yog lawm, peb tuaj yeem muab cov qauv dawb rau kev kuaj, thiab tus neeg yuav khoom yuav tsum them tag nrho cov nqi xa khoom.
Q: Koj puas kam txais cov xaj me me?
A: Koj tsis tas yuav txhawj txog qhov teeb meem no, tsuas yog thov kev tawm tswv yim.
Q: Koj puas lees txais kev tshuaj xyuas thib peb?
A: Yog, peb lees txais nws kiag li.
